Trench IGBT Overview
Data processing...
Product selection| TYPE | VCES(V) | IC(A) | VEC(sat)(V) | Ptot(W) | Eoff(mJ) | Rth/JC(℃) | Vth(V) | Package | Operation |
|---|---|---|---|---|---|---|---|---|---|
| THG05T65NF | 650 | 5 | - | - | - | - | - | - | Specification Consulting |
| THG15T65NK | 650 | 15 | 1.90 | - | - | - | 6.00 | TO-247 | Specification Consulting |
| THG20T65NK | 650 | 20 | 2.00 | - | - | - | 6.10 | TO-247 | Specification Consulting |
| THG20T65FF | 650 | 15 | 1.90 | - | - | - | 5.50 | TO-220F | Specification Consulting |
| THG25T65NK | 650 | 25 | 2.00 | - | - | - | 6.00 | TO-247 | Specification Consulting |
| THG30T65NK | 650 | 30 | 1.90 | - | - | - | 6.00 | TO-247 | Specification Consulting |
| THG40T65NK | 650 | 40 | 2.00 | 230 | - | - | 5.70 | TO-247 | Specification Consulting |
| THG40T65FK | 650 | 40 | 2.00 | 230 | - | - | 5.00 | TO-247 | Specification Consulting |
| THG50T65FK | 650 | 50 | 2.00 | 265 | - | - | 5.00 | TO-247 | Specification Consulting |
| THG60T65NK | 650 | 60 | 1.90 | 300 | - | - | 6.00 | TO-247 | Specification Consulting |
| THG60T65FK | 650 | 60 | 1.95 | 300 | - | - | 5.00 | TO-247 | Specification Consulting |
| THG75T65FK | 650 | 75 | 1.70 | 385 | - | - | 5.50 | TO-247 | Specification Consulting |
| THG15T120FK | 1200 | 15 | 1.90 | 200 | - | - | 5.50 | TO-247 | Specification Consulting |
| THG25T120FK | 1200 | 25 | 1.95 | 326 | 5.50 | - | - | TO-247 | Specification Consulting |
| THG40T120FK | 1200 | 40 | 1.85 | 395 | - | - | 5.50 | TO-247 | Specification Consulting |
| THG50T120FK | 1200 | 50 | 1.95 | 535 | - | - | 6.00 | TO-247 | Specification Consulting |
| THG75T120FP | 1200 | 75 | 1.85 | 635 | 6.00 | - | - | TO-247 | Specification Consulting |
| THG100T120FPL | 1200 | 100 | 2.10 | 750 | - | - | 6.00 | TO-247 | Specification Consulting |
